Waste water treatment system

1.The waste water treatment system is used for cleaning waste water from the recycling line .The main contaminants is PH,BOD5,COD,SS,oil and ect.After treatment the water can be reused again in the recycling line or can be discharged to public channel.

2.The capacity of the waste water treatment system is from 5t-30t/hr according to the different capacity of the recycling line.

3.Machine list:

No. Name Model Quantity Remark
1


Water lifting pump  G35-65  1 Taiwan,4KW
Flux meter  LZS-50  1
2 Reactive tank  2000×1000×1100  1  With mxer 0.25KW
3




Sloped pipe setting tank  ZTX——7.5t/h  2  Steel ,anticorrosion
Sloped pipe    8M²
Sludge pump  666120-3EB-C  2
4 Medicine add system  φ1050×1210  3  With pump
5


PH adjust tank  2500×1000×1600  1  Steel ,anticorrosion
PH meter  0-14  1
6 Sand tower  φ1200×2500  1  With additives
7 Activated carbon adsorption tower  12800×2500  1  With additives
8 Filter back flush pump  G37-65  1  Taiwan 5.5KW
9 Liquid level meter    4  anticorrosion
10






Board filter  XMJ30/800—U—I  1  1.5KW
Frame    1
Water pallet  1500×1000  2
Sludge filter pump  666170-3EB-C  1
11 Sludge box  2500×1000×1600  1 Steel ,anticorrosion
12 Magnetic valve  DN15  4
13 Electric control system    1 Automatic
14 Operating table    1
15 Pipeline and pipe fitting    1
